Wall mounted vertical cutting machine with two cutting heads. Cuts semi-rigid materials (up to 22mm thick) and glass (up to 3mm thick).
- Two exchangeable cutting heads included - cutting head for glass and knife for semi-rigid materials
- Cuts semi-rigid and rigid materials like foamboard, cardboard, corrugated plastic and glass
- For sizes up to 305cm
- Laser for cutting head available as option
|MODEL ||Wincut 160 ||Wincut 246 ||Wincut 305 |
|Compressor ||Not included ||Not included ||Not included |
|Max. Cutting Length (mm) ||1600 ||2460 ||3050 |
|Max. Cutting Depth (mm) ||22 ||22 ||22 |
|Net Weight (kg) ||120 ||182 ||218 |
|Dimensions WxDxH (mm) ||1920 x 500 x 2390 ||2460 x 560 x 3300 ||2460 x 620 x 3860 |
|Power ||1-ph ||1-ph ||1-ph |
|Warranty (yrs) ||1 ||1 ||1 |
For more information, see attachments below.
